Pro iCAN Signature

Specifications

THD n

Solid-State: ≤0.0015% balanced / ≤0.005% single-ended; Tube: ≤0.002% balanced / ≤0.005% SE; Tube+: ≤0.012% balanced / ≤0.2% SE

Weight

1.93 kg / 4.3 lb (net)

Outputs

4.4mm balanced Pentaconn, fully balanced XLR, single-ended 6.3mm, and proprietary S-Balanced 3.5mm (claimed to cut distortion ~50% vs. standard single-ended)

Topology

Hybrid "TubeState" design — fully discrete, fully balanced, DC-coupled, switchable tube/J-FET input stage with bipolar second stage and MOSFET-buffered bipolar Class A(B) power stage

Dimensions

213 × 193 × 63 mm (6.2" × 3.9" × 1.4")

Power output

Balanced >14,000 mW @ 16Ω, >23V @ 600Ω; Single-ended >4,800 mW @ 16Ω, >11.5V @ 600Ω

Power supply

Bundled iFi iPower Elite outboard AC/DC supply; consumption <22W idle, up to 50W max

Gain settings

0 dB, 9 dB, 18 dB (user-selectable switch)

Operating modes

Solid-State, Tube, and Tube+ (user-selectable)

Frequency response

0.5 Hz–500 kHz (−3 dB)

Signal to noise ratio

>147 dB(A) balanced; >137 dB(A) single-ended
