Döhmann Audio

Schröder CB-9 Tonearm

MSRP not recorded

The Schröder CB-9 is a 9-inch tonearm made by Frank Schröder and featuring a captive-bearing design with magnetically centered, pre-loaded ceramic hybrid bearings. It has 2 mg vertical and 3.5 mg horizontal measured bearing friction, internal magnetic damping for horizontal movement, and eddy-current damping for lateral motion. The arm wand is available in carbon fibre or Kingwood, with 239.3 mm effective length, 222.0 mm pivot-to-spindle distance, 14 g effective mass with the supplied mounting plate, adjustable azimuth and VTA, and a dual-section counterweight with adjustable damping.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

Wiring: Cryogenically treated, low loss, high purity copper wiring. Single run from cartridge clips to RCAs. 1m length from arm to RCAs. (additional lengths available upon request)
Overhang: 17.3 mm
Metal colour: Black
Offset angle: 23°
Mounting hole: 24-25mm with single M6 tapped hole
Arm wand length: 9 inches
Arm wand material: Carbon Fibre or Kingwood
Shaft diameter: 23 mm
Effective length: 239.3 mm
Double counterweight: Lower counterweight can be exchanged to an optional lighter or heavier cylinder, allowing for an increase/decrease of total counterweight mass without altering the overall mass distribution of the arm. Adjustment to a fundamental arm cartridge resonance frequency of 8-12Hz yields optimal performance
Adjustable parameters: VTF VTA Overhang Offset angle Azimuth Anti-skating Frictionless, resonance free magnetic anti-skating up to 2.3 grams. VTF higher tracking forces can be compensated for by exchanging the anti-skating screw, upon request.
Balance characteristics: Neutral balance arm, no change in VTF when altering VTA or record thickness. Internal magnetic damping for the horizontal movement
Pivot to spindle distance: 222.0 mm
Ceramic hybrid bearing friction: > 2mg vertically, > 3.5mg horizontally
Distance between mounting surface and platter level: 25-60mm, best ~30-35mm
Effective mass with supplied cartridge mounting plate grams: 14
Effective mass with optional heavy cartridge mounting plate grams: 19
Effective mass with optional ultra light cartridge mounting plate grams: 12.5
