Pro-Ject Audio Systems

Signature Tonearms 9“

MSRP not recorded

The Pro-Ject Audio Systems Signature Tonearm 9" is a single-pivot tonearm with an SME headshell connection and a classic S-shaped tube made from specially damped aluminium. It uses an oil-damped uni-pivot design, a non-magnetic low-resonance construction, azimuth adjustment, and a 12 g diamond-cut aluminium headshell with built-in fingerlift and 1/2-inch cartridge mounting; optional Wood and Carbon headshells weigh 8 g and 10 g, respectively. The tonearm has a 230.0 mm effective length, 212.0 mm mounting distance, 24° offset angle, 18.0 mm overhang, 17.2 g effective mass including the aluminium headshell, a 77 mm counterweight rotation diameter, and a stated 5–23 g cartridge-weight range depending on headshell weight.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

Counterweight rotation diameter in: 77 mm
Overhang in MM from the spindle to the stylus: 18.0
Offset angle between a groove and the stylus direction: 24°
Mounting distance from the tonearm pivot to the spindle: 212.0
Effective tonearm lenght in MM from the tonearm pivot to the stylus: 230.0
Effective tonearm mass in grams 172 185 195 including alu headshell: 17.2
Cartridge weight range in grams 5 23 5 25 5 25 depending on individual headshell weight: 5-23
