Nagra

Classic PHONO

MSRP not recorded

The Nagra Classic PHONO is a phono stage manufactured by Nagra, designed for moving-coil and moving-magnet cartridges. It uses custom-made Nagra input transformers, a fully tube-based Class A topology with four triodes—2× E88CC/6922, 1× ECC81/B739, and 1× ECC83/B759—and an internal 100–240 V power supply, with optional Classic PSU support. It provides adjustable gain from 37.7 to 63.9 dB, selectable RIAA, TELDEC, and COLUMBIA curves, adjustable cartridge loading, and mono operation.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

1: MM 增益开关低点 37.7 dB 增益开关高点 47.7 dB MC 增益开关低点 53.9 dB 增益开关高点 63.9 dB kHz
Nagra: 2 個 E88CC / 6922 1 個 ECC81 / B739 1 個 ECC83 / B759
SNR: > -82 dB (ASA A) With dummy loads connected to the inputs
Crosstalk: > -75 dB (typically > -82 dB)
Dimension: 350 (390 from nose of the modulometer to back of the connectors) x 277 x 80mm (15.4 x 10.9 x 3.2 inches) – Add 3cm or 1.2 inches with a VFS plate placed under
Mains fuse: T 500 mA FST 5 x 20 mm 250 V
Weight: 5.4 kg 11.9 lbs CLASSIC PHONO unit alone with 1x MC / MM input and 1x MC input
Output level: 1 V RMS for 0 dB Large tolerance to smoothly provide 2 V RMS
Power supply: Internal 100 240 V~ ±10% / 50-60 Hz With Mains or with optional CLASSIC PSU 1x 12.6 V / 1.5 A w (Standby <1 W)
Output impedance: < 500 Ω (typically 470 Ω)
Power consumption: PMAX 35 W
Transformer ratio: 16 dB
Frequency response: 20 Hz 50 kHz +0.6 dB RIAA, TELDEC, -0.2 dB COLUMBIA LP 100 Hz 50 kHz +/- 0.2 dB
Interchannel phase: < 4° (typically 0.35°) @ 20 kHz
Operating environment: Indoor only IP30
Operating temperature: +15 °C to +35 °C Moderate climate +59 °F to +95 °F
Tube stage gain 1 khz no load: MM Gain switch LOW 37.7 dB Gain switch HIGH 47.7 dB MC Gain switch LOW 53.9 dB Gain switch HIGH 63.9 dB
Total harmonic distortion THD n: Please refer to the below graph
Vacuum tubes selected by nagra laboratory: 2x E88CC/ 6922 1x ECC81/B739 1x ECC83/B759
