Perlisten Audio

D8is

MSRP not recorded

The Perlisten D8is is a subwoofer designed for freestanding, on-wall, or in-wall installation, with an acoustic-suspension alignment and a full-aluminum extruded enclosure. It uses eight 215 mm (8.5-inch) drivers with carbon-fiber diaphragms and ±18.0 mm linear excursion in a push/pull force-cancelling configuration. An external DSP-controlled 3,000 W RMS amplifier provides a 32-bit ARM Cortex M4 processor, 48-bit DSP data paths, a 2.8-inch color touchscreen, iOS and Android control, and a stated frequency response of 20–290 Hz at −6 dB with THX EQ.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

App: iOS and Android
Phase: variable 0-270o
Inputs: (1) Balanced XLR (1) Unbalanced RCA
Outputs: (1) Balanced XLR unbuffered (1) Unbalanced RCA unbuffered (1) Digital AES/2
Polarity: normal / inverted
Alignment: Acoustic suspension
Processor: 32-bit ARM Cortex M4, double precision floating point math
Dsp engine: Ti DSP 48-bit data paths
Weight: 103.8 kg (228.4 lbs) 6.1 kg (13.4 lbs) 191.1 kg (422.2 lbs)
Parametric EQ: 10-Band PEQ with 3 user presets
Sensitivity: 97.0 dB /150mV/ 1.0m
Amplifier class: 89.0 x 429.2 x 322.4mm 3.5 x 16.9 x 12.7"
Low pass filter: bypass, 30-160Hz, slope 6,12,18,24dB/oct
Display interface: 2.8" LCD color touchscreen
Driver compliment: (8)215mm (8.5"), Carbon fiber diaprhragm +/-18.0mm linear excursion
Available finishes: Black anodized aluminum matte black
Configurable auto turn on and 12v trigger: XLR, RCA
Subwoofer dimensions overall hxwxd see architectural drawing: 1137.6 x 508.0 x 238.6mm (without brackets) 44.8 x 20.0 x 9.4"
Frequency response thx EQ boost large room EQ cut small room EQ: 20-290Hz (-6dB) / 16-330Hz (-10dB) 16-290Hz (-6dB) / 14-330Hz (-10dB) 25-290Hz (-6dB) / 19-330Hz (-10dB)
