Perlisten Audio

D3is

MSRP not recorded

Perlisten Audio D3is is an active sealed subwoofer in the D-series made by Perlisten Audio (USA), designed for wall-mount, in-wall, or cabinet installation. It uses three 215 mm bass drivers with carbon-fiber diaphragms and an external 1500 W amplifier with 48-bit DSP, a 32-bit ARM Cortex M4 processor, a 10-band parametric equalizer, and a 2.8-inch color LCD screen. Its frequency range is 17–290 Hz, with XLR and RCA inputs and outputs; dimensions are 921 × 356 × 146 mm and weight is 39.7 kg.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

App: iOS and Android
Phase: variable 0-270o
Inputs: (1) Balanced XLR (1) Unbalanced RCA
Outputs: (1) Balanced XLR unbuffered (1) Unbalanced RCA unbuffered (1) Digital AES/2
Polarity: normal / inverted
Alignment: Acoustic suspension
Processor: 32-bit ARM Cortex M4, double precision floating point math
Dsp engine: Ti DSP 48-bit data paths
Weight: 39.7 kg (87.3 lbs) 6.1 kg (13.4 lbs) 53.4 kg (117.5 lbs)
Parametric EQ: 10-Band PEQ with 3 user presets
Sensitivity: 89.5 dB /150mV/ 1.0m
Amplifier class: 89.0 x 429.2 x 322.4mm 3.5 x 16.9 x 12.7"
Low pass filter: bypass, 30-160Hz, slope 6,12,18,24dB/oct
Display interface: 2.8" LCD color touchscreen
Driver compliment: (3)215mm (8.5"), Carbon fiber diaprhragm +/-16.9mm linear excursion
Available finishes: Matte black
Configurable auto turn on and 12v trigger: XLR, RCA
Subwoofer dimensions overall hxwxd see architectural drawing: 920.8 x 355.6 x 146.1mm (without brackets) 36.3 x 14.0 x 5.8"
Frequency response thx EQ boost large room EQ cut small room EQ: 20-290Hz (-6dB) / 16-350Hz (-10dB) 17-290Hz (-6dB) / 15-350Hz (-10dB) 31-290Hz (-6dB) / 23-350Hz (-10dB)
