Pro-Ject Audio Systems

Record Box E

MSRP not recorded

Record Box E, made by Pro-Ject Audio Systems, is a phono preamplifier with RIAA equalization for MM and MC cartridges, an integrated A/D converter, and USB output for digitizing vinyl. It provides 40 dB MM gain and 60 dB MC gain, uses a Burr Brown PCM2904 16-bit Delta-Sigma converter with 32, 44.1, and 48 kHz sampling rates, and has USB 1.1 digital serial output. The circuit uses SMD construction with low-noise components, internal metal shielding, gold-plated RCA sockets, and an external 18 V/500 mA DC power supply; it measures 120 × 32 × 100 mm, or 115 mm deep with sockets, and weighs 250 g without the power supply.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

THD MM MC: <0,01% / <0,05%
Gain MM MC: 40 dB / 60 dB
Max output: 9,5 V (1 kHz)
USB output: 5 pin Mini b Buchse
USB signal: digital serial data protocol USB 1.1
Weight: 250g without power supply lbs
A d converter: Burr Brown PCM2904 16-Bit Delta Sigma
Dimensions: 120 x 32 x 100 (115) mm"
Sampling rates: 32, 44,1 and 48 kHz
Input line output: 1 pair RCA/Cinch sockets each
Noise floor MM MC: 94 dB (A weighted) / 75 dB (A weighted)
Operating systems: Windows XP®, Windows Vista®, Windows 7®, Windows 8®, Mac OS, Linux
Power consumption: 100 mA DC
Outboard power supply: 18 V / 500 mA DC, suitable for your country s mains supply
Output voltage typically: 300 mV/1 kHz bei 3 mV/1 kHz (MM) oder 0.3 mV/1 kHz (MC)
Riaa equalisation curve accuracy: 20 Hz - 20 kHz / max. 0.5 dB
Input capacitance input impedance: MC: 100 ohms/120 pF (low output MC) MM: 47kohms/120 pF (MM or high output MC)
