Aavik
C-580
The Aavik C-580, made by Aavik, is a separate control/pre amplifier with line inputs, RCA line output, 76 dB volume control in 1 dB steps, and an optional active analog crossover adjustable from 60–160 Hz. Its line stage uses an inverted virtual-GND amplifier topology, with <0.005% THD, 10 kΩ input impedance, 50 Ω output impedance, and maximum output of 8.5 Vrms. The unit incorporates 108 active Tesla coils, 228 active square Tesla coils, 10 dither-circuitry stages, a switchless optical input board, and a solid-copper inner chassis; it measures 400 × 384 × 102 mm and weighs 8.1 kg.
MSRP
—
Original list price not on record.
Used market
No tracked sales yet
MSRP to used market
Price history will fill in as sales are recorded.
Specifications
- Standby
- <1W
- Line out
- 1 x RCA
- L x w x h
- 400 x 384 x 102 mm
- Operating
- <12W
- Max output
- 8,5Vrms
- Weight
- 8.2 kg lbs
- Gain line 5
- 1-11dB; max input 6,5V RMS
- Gain line 1 4
- 5-15dB; maximum input 4.5V RMS
- Low pass slope
- 24dB/octave
- High pass slope
- 12dB/octave
- Input impedance
- 10K ohm
- Dither circuitry
- 10
- Output impedance
- 50 ohm
- Active tesla coils
- 108
- Crossover frequency
- 60-160Hz
- Distortion line stage
- <0,005% (THD at 1kHz, 1V input)
- Active square tesla coils
- 228
