Pro-Ject Audio Systems

DAC Box RS Final Edition

MSRP not recorded

The DAC Box RS Final Edition is a digital-to-analog converter by Pro-Ject Audio Systems for digital stereo sources and USB computer audio. It uses two Texas Instruments PCM1792 DAC chips, supports PCM up to 24-bit/192 kHz and DSD128, and provides USB, AES/EBU, optical, coaxial, and I²S inputs with selectable steep or optimum-phase digital filters. Its fully balanced analog circuitry offers switchable ECC88 diamond-selection tube and solid-state Class A output stages, RCA and XLR outputs, a 20 V/3 A external DC power supply, and a full-metal casing available in silver or black.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

SNR: 100 dB
Weight: 1890g without power supply lbs
THD: 0.005% solid state out%
Analogue out: RCA / Cinch & XLR
D a converter: 2 x Texas Instruments PCM-1792 8 x Oversampling design
Dimensions: 206 x 72 x 210 mm with sockets"
Output stages: ECC88 Diamond selection high-end tube and solid state (switchable)
Digital inputs: 2 x coax (S/PDIF)
Output voltage: max 4V/ 2V (XLR/RCA) at 1k Hz
Sampling rates: 32 / 44,1 / 48 / 88,2 / 96 / 176,2 / 192 kHz (except optical up to 96kHz)
Power consumption: <1 watt standby, 800/300mA max (tube/solid)
Frequency response: 20Hz - 50kHz (+0/-1dB)
Outboard power supply: 20V/3A DC (included)
Precision clock output: BNC (use with CD Box RS)
Selectable filter settings: „steep“ & „optimum phase“
