Rega

Fono MC

MSRP not recorded

The Rega Fono MC MK4 is a moving-coil phono preamplifier made by Rega for amplifying MC cartridge signals to a 200 mV line-level input. It uses an all-discrete input stage with a Linear Systems LSK389 FET, a MUSE operational amplifier for RIAA equalization, and polypropylene capacitors in the signal path and RIAA circuits. Rear-panel switches provide selectable resistance loading of 70–400 Ω, capacitance loading of 1000 or 4300 pF, and gain of 63.5 or 69.5 dB; specifications include 13 Hz–100 kHz frequency response, ±0.2 dB RIAA accuracy from 100 Hz to 100 kHz, 200 Ω output impedance, and 24 V AC/150 mA maximum power requirements for use with the Rega PS1.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

Output impedance: 200 Ω
Power requirements: 24 V AC at 150 mA maximum
Input loading resistance: 1 and 2 off = 400 Ω / 1 on = 100 Ω / 2 on = 150 Ω / 1 and 2 on = 70 Ω
Input loading capacitance: 3 off = 1000 pF / 3 on = 4300 pF / Gain (at 1 kHz) / 4 off = 63.5 dB / 4 on = 69.5 dB
Maximum input level at 1: 4 off = 6.7 mV / 4 on = 3.4 mV kHz
Riaa accuracy 50 k output load: Better than ±0.2 dB 100 Hz to 100 kHz
Frequency response 50 k output load: 13 Hz (-3 dB) to 100 kHz (-0.3 dB)
Input sensitivity for 200 mv output: 4 off = 133 uV / 4 on = 67 uV
Recommended minimum output load resistance: 5 k
Factory settings for all rega MC cartridges: Impedance 100 Ω / Capacitance 1000 pF / Gain Setting High
