Nagra

Classic AMP

MSRP not recorded

The Nagra Classic AMP is a high-power solid-state stereo amplifier made by Nagra. It operates in pure Class A over a broad power range and in Class AB beyond that, with output stages based on tandem MOSFET transistors, an overdimensioned transformer, diode-bridge power supply, PFC decoupling, and 300,000 μF of filtering capacitance. It delivers 100 W RMS per channel into 8 Ω, supports balanced and unbalanced inputs, bridged operation at 200 W into 4 Ω, and bi-amplification.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

Size: 350 (400 from nose of the modulometer to back of the connectors) x 277 x 165mm (15.7 x 10.9 x 6.5 inches) – Add 3cm or 1.2 inches with a VFS plate placed under
Power: 100 W RMS per channel into 8 Ω
Bandwidth: 10 Hz to 80 KHz, +0/-3 dB
Crosstalk: >70 dB
Protection: Overheating > +60° C (140° F)
Weight: 18 Kg (39 lb 10 oz) lbs
Consumption: 400 W max less than 1 W in standby and Auto mode
THD: < 0.05%%
Sensitivity: 1 V or 2 V RMS dB
Automatic start: For input level >10 mV
Input impedance: >100 KΩ
Operating range: 90 – 110 V or 110 -132 V or 180 – 264 V a.c. 50 – 60 Hz
Signal to noise ratio: Typically 110 dB ASA “A” weighted
Deactivates the amplifier: DC speaker protection above ± 2.5 VDC
