Nagra

MSA

MSRP not recorded

The Nagra MSA is a stereo amplifier manufactured by Nagra from 2010 to 2014. It uses Class AB amplification, delivers 60 watts RMS per channel into 8 ohms, and can be bridged for 120 watts RMS into 4 ohms; its output stages use a pair of MOSFET transistors in push-pull, common-source configuration, with an active-feedback switching-mode power supply incorporating PFC. The amplifier has a brushed-aluminium chassis, a 3 kg solid-aluminium-block-milled heat sink, XLR inputs, binding-post speaker terminals, a 10 Hz–75 kHz bandwidth, and a weight of 9.5 kg.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

Power: 60 watts RMS stereo 8Ω input 1 or 2 V 120 watts RMS bridged into 4Ω
Bandwidth: 10 Hz – 75 kHz +0/-0.3 dB
Monitoring: Front LED blinks if output current >9 A
Weight: 9.5 kg (20.9 lbs)
Mains power: 100 V, 120 V, 230 V at 50/60 Hz
Dimensions: 280 x 230 x 118 mm (11 x 9 x 4.6 inches) L x D x H"
Amplifier class: AB
Automatic start: Input signal >10 mV
Input impedance: 50 kΩ
Input connectors: XLR (Symmetrical)
Power consumption: Max 232 W, in stand-by (auto position) 1 W
Security circuits: Disconnect power stages if temperature >60°C (140°F) D.C. Speaker protection if DC >2.5 V
Channel separation: Typically 70 dB at 10 kHz
Harmonic distortion: <0.1%
Loudspeaker terminals: Binding posts (Cables up to 4.2mm, banana plugs 4 mm, spade 6.35 mm)
Signal to noise ratio: 109 dB ASA-A weighted
