L-509Z

Specifications

THD

0.007% or less at 8 ohms, 1kHz; 0.03% or less at 8 ohms, 20Hz-20kHz

Inputs

4 pairs single-ended RCA line inputs (Line 1/2 use high-rigidity terminals), 2 pairs balanced XLR line inputs, MAIN IN (RCA), switchable MM/MC-H/MC-L phono input. Sensitivity/impedance: MM 2.5mV/47k, MC-H 0.3mV/100 ohm, MC-L 0.1mV/40 ohm, Line 180mV/47k, Balanced 180mV/79k, Main In 1.1V/47k

Weight

29.4 kg (64.6 lb)

Outputs

Two sets of speaker terminals with independent on/off switching (bi-wire capable), PRE OUT (1V), REC OUT and Monitor RCA outputs, 6.3mm headphone jack plus 4.4mm balanced headphone jack

Dimensions

440 W x 193 H x 463 D mm (17.3" x 7.6" x 18.2")

Accessories

RA-17A remote control and power cable

Power output

120W + 120W into 8 ohms; 220W + 220W into 4 ohms

DAC / Streaming

None (no DAC or streaming specified)

Tone controls

Bass +/-8dB at 100Hz, Mid +/-8dB at 760Hz, Treble +/-8dB at 10kHz; LECUA-EX volume with 88 steps

Damping factor

330 (current injection method)

Published price

14495 USD

Signal to noise

MM phono >87dB, MC-H >70dB, MC-L >62dB, Line >106dB (IHF-A)

Power consumption

390W maximum; 150W no signal; 0.5W standby

Power into 4

220 W Ω

Power into 8

120 W Ω

Frequency response

Phono: 20Hz-20kHz +/-0.5dB; Line: 20Hz-100kHz, within -3dB
