PD-191A

Specifications

Gain

MM 38dB, MC-H 57dB, MC-L 66dB

Motor

Brushless DC motor with PID control

Bearing

Concealed vertical knife edge

Material

Machined aluminum, Surface finish: Diamond cut

Overhang

16mm

Net weight

13.2kg (main unit)

Revolution

33 1/3rpm, 45rpm, 78rpm (3 speeds selectable)

Weight

25.4 kg (main unit) lbs

Accessories

Power cable

Anti skating

0 to 4g

Drive system

Belt drive system

Power source

230V～50Hz / 115V～60Hz

Power supply

230V~(50Hz) / 115V~(60Hz)

Rated output

120W + 120W (8Ω) 220W + 220W (4Ω)

D a converter

ROHM BD34352EKV (monaural mode) x 2

Digital input

Network : 1000 Base-T (gigabit · ethernet) HDMI : PCM 2 channel, 4K pass-through ARC (Audio Return Channel) supported

Dimensions

440 (W) × 178 (H) × 454 (D) mm front side knob of 20 mm and rear side terminal of 27 mm included in depth"

Load capacity

MM 0 / 100 / 200 / 320pF

Maximum input

MM 120mV, MC-H 15mV, MC-L 5mV

Riaa response

MM 20Hz to 20kHz (±0.1dB), MC 20Hz to 20kHz(±0.3dB)

Damping factor

330

Digital output

USB (USB2.0), OPT, COAX HDMI : PCM 2 channel, 4K pass-through ARC (Audio Return Channel) supported

Insulator feet

Density gradient

Output voltage

PRE OUT: 1V

Volume control

New LECUA1000

Amplifier class

LIFES 1.0

S n ratio ihf a

MM 88dB, MC-H 81dB, MC-L 78dB

Supported discs

CD, MQA-CD

Wow and flutter

0.04% or less (W.R.M.S.)

Effective length

256mm

Supported discsm

SACD, CD (CD-R, CD-RW, MQA-CD)

Input sensitivity

MM 3.2mV, MC-H 0.37mV, MC-L 0.12mV

Power consumption

13W

Power transformer

OI type x 3 (L/R independent + Peripheral circuit)

Volume adjustment

LECUA-EX

Channel separation

80dB or more

Frequency response

PHONO: 20Hz to 20kHz (±0.5dB) LINE: 20Hz to 100kHz (within -3dB)

Rated output power

20 W + 20 W (8 Ω), 40 W + 40 W (4 Ω)

Storage connection

USB x 2 terminals (USB2.0, single partition, FAT32, exFAT, NTFS)

External dimensions

440(W) x 92(H) x 407(D) mm front side knob of 14mm and rear side terminal of 37mm included in depth

Streaming protocols

UPnP (OpenHome), TIDAL Connect, Spotify Connect, Roon Ready

Output configuration

Bipolar 4-parallel push-pull

Power supply voltage

230V~(50Hz)/115V~(60Hz)

Tracking error angle

+1.07° to -1.52°

Circuit configuration

Non-feedback type phono equalizer (RIAA, first stage four parallel FET, unbalanced configuration)

MC step up transformer

Super permalloy core x 4 (L/R channel, L/H impedance independent) : 0.3mV / 100Ω

Adjustable height range

22mm

Instantaneous max output

Unbalanced:5W + 5W (8Ω) Balanced:20W + 20W (8Ω)

Total harmonic distortion

0.003%

Max amount of tone control

BASS: ±8dB at 100Hz TREBLE: ±8dB at 760Hz TREBLE: ±8dB at 10kHz

Applicable cartridge weight

4 to 11g (including headshell 17 to 24g)

Revolution adjustment range

±6% (each rotation speed adjustable independently)

Signal to noise ratio ihf a

PHONO (MM): 80 dB or more PHONO (MC): 65 dB or more LINE: 98 dB or more

Corresponding format formats

WAV, AIFF, FLAC, ALAC, MQA, MP3, AAC, DSD (DSF, DFF)

Rated output output impedance

250mV / Unbalanced 300Ω, Balanced 600Ω

Supported sampling frequencies

USB input (PCM) : 44.1 kHz, 48 Hz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, 352.8 kHz, 384 kHz (16, 24, 32-bit) USB input (DSD) : 2.8 MHz, 5.6 MHz, 11.2 MHz, 22.5 MHz (1-bit) Coaxial / Optical input : 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz (16, 20, 24-bit), 2.8 MHz (DoP)

Analog output voltage impedance

Unbalanced : 2.4 V / 300 Ω, Balanced : 2.4 V / 600 Ω

Maximum tone control adjustment

BASS: ±8 dB at 100 Hz TREBLE: ±8 dB at 10 kHz

Input sensitivity input impedance

PHONO (MM): 2.5 mV / 47 kΩ PHONO (MC): 0.3 mV / 100 Ω LINE: 180 mV / 47 kΩ BAL.LINE: 180 mV / 55 kΩ MAIN-IN: 450 mV / 47 kΩ

Speaker terminal supported y lug terminal dimension

Width of part a: 16mm or less Width of part b: 7mm or more * Connection may not be performed depending on the shape of the Y-lug terminal.

Speaker terminals supported y lug terminal dimension

Width of part a : 15 mm or less Width of part b : 8 mm or more * Connection may not be performed depending on the shape of the Y lug terminal.

440 w x 92 h x 398 d MM front side display of 3 MM and rear side terminal of 13 MM included in depth

Net weight
