PS Audio
Stellar Strata MK2
The Stellar Strata MK2 is an integrated stereo audio component combining a fully balanced Class A analog preamplifier, full-function DAC, MC/MM phono stage, Class A headphone amplifier, and MOSFET-based 150-watt-per-channel power amplifier. Its digital section provides two I²S, two coaxial, one optical, and one USB input, supporting PCM up to 384 kHz and DSD formats up to DSD256 via I²S. The amplifier provides 100 watts minimum per channel into 8 ohms and 150 watts typical into 4 ohms, with RCA and XLR analog inputs, speaker binding posts, and a ¼-inch headphone output.
MSRP
$3,499
Used market
No tracked sales yet
MSRP to used market
Price history will fill in as sales are recorded.
Specifications
- Imd
- 18/19KHz -65dB
- Gain
- 40dB; 57dB
- Fuses
- T250V-250mAH (1/4A Slow Blow)
- Other
- Trigger Out: 2 3.5mm, 5-15 DVC USB A: 1 (for firmware update)
- SNR
- 1KHz >110dB (max output)
- Loading
- 100pF/47kΩ; 470pF/100Ω
- Location
- Indoor use only
- Input trim
- Gain adjustable per input +/-10dB
- Weight
- 21 lbs [9.5 kg]
- THD
- .001% @ 5mV input; .003% @1mV input%
- Output noise
- < -90dBV
- Output power
- 8Ω, 1KHz, 1% 100W minimum 4Ω, 1KHz, 1% 150W typical
- Phono inputs
- MM RCA: 1 stereo pair MC RCA: 1 stereo pair
- Audio outputs
- RCA (Unbalanced): 1 stereo pair Headphones: 1 1/4" stereo Speakers: 2 binding post pairs
- Color options
- Black Silver
- Input voltage
- US 108—132VAC (120VAC nominal) EX/GR/UK/AU 207—253VAC (230VAC nominal) JP 90—110VAC (100VAC nominal)
- Phase control
- Digital sources only
- Cartridge type
- MM; MC
- Damping factor
- 50Hz, 4Ω 29
- Filter control
- 3 selectable digital filters (PCM digital sources only)
- Headphone trim
- Gain adjustable +/-10dB relative to speaker level
- Sensitivity
- @76 1.77 VRMS @100 450 VRMS dB
- Volume control
- 0-100 (80 dB total range)
- Balance control
- 12dB each direction in 1/4dB steps
- Input impedance
- 47KΩ (unbalanced); 100KΩ (balanced)
- Input selection
- 9 total: 2 analog, 6 digital, 1 Phono
- Shipping weight
- 25 lbs [11.4 kg]
- Unit dimensions
- 17" w x 2.8" h (not including feet) x 13.5" d (with connectors and knobs, chassis only is 12") [43.2cm x 7.1cm x 34.3cm]
- Voltage options
- Japan 100V (+/-10%) North America 120V (+/-10%) Europe/Asia 230V (+/-10%)
- Input separation
- >85dB
- Output impedance
- Line Out 100Ω
- Fixed volume mode
- Analog2: adjustable in setup to any level
- Mains power input
- IEC C14
- Power consumption
- Idle 20W Typical 50W Maximum 600W
- Speaker impedance
- 4Ω minimum
- Channel separation
- 1KHz >90dB
- Frequency response
- +/-1dB 20Hz – 20KHz -3dB 7Hz – 40KHz
- Analog audio inputs
- RCA: 2 stereo pairs XLR: 1 stereo pair
- Headphone impedance
- 8Ω minimum
- Maximum input level
- >16 VRMS
- Shipping dimensions
- 22" w x 8" h x 17" d [55.9cm x 20.3cm x .4.3cm]
- Storage temperature
- -30 to 70C
- Accessories included
- Remote Control Line Cord: - US, JP and EX (NEMA 5-15P) - Schuko (CEE7/7) (230V version) - UK (BS1363) (230V version) - Australia (230V version)
- Digital audio inputs
- I2S: 2 inputs - PCM 44.1KHz to 384Khz, DSD64, DSD128, DSD256 Coax: 2 inputs - PCM 44.1KHz - 192KHz Optical: 1 input - PCM 44.1kHZ - 192KHz USB: 1 input - PCM 44.1kHZ - 384KHz - DSD64, DSD128 (native) - DSD64, DSD128 (DoP)
- Operating temperature
- 0 to 45C
- Gain relative to line output
- 30.5dB
