Harmonic Resolution Systems (HRS)

M3X2 Isolation Base

MSRP not recorded

The M3X2 Isolation Base is an audio-component isolation platform manufactured by Harmonic Resolution Systems (HRS). It is approximately 3 inches high and constructed from more than 70 parts and six materials, including two proprietary polymers, billet-machined aircraft aluminum, and polished black granite. Its design combines a granite contact plate, two internal resonance-control stages, and selectable HRS Broadband Isolation Feet (SF), Low Frequency Feet (LF), or Bi-Directional Noise Reduction Feet (G7); it is available in six standard sizes and custom sizes.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

M3x2 1419 b black s silver: 19″ X 14″ X 3″ (48.3 X 35.6 X 7.6); 34.8 LB 15.8 KG; YELLOW (YL) 0 – 25 LB (0 – 11.4 KG) RED (RD) 26 – 57 LB (11.5 – 25.9 KG) GREEN (GN) 58 – 102 LB (26 – 46.4 KG) BLUE (BL) 103 – 171 LB (46.5 – 77.7 KG)
M3x2 1719 b black s silver: 19″ X 17″ X 3″ (48.3 X 43.2 X 7.6); 41.9 LB 19.1 KG; ORANGE (OR) 0 – 30 LB (0 – 13.6 KG) RED (RD) 31 – 49 LB (13.7 – 22.3 KG) GREEN (GN) 50 – 94 LB (22.4 – 42.7 KG) BLUE (BL) 95 – 163 LB (42.8 – 74.1 KG)
M3x2 1921 b black s silver: 21″ X 19″ X 3″ (53.3 X 48.3 X 7.6); 51.7 LB 23.4 KG; ORANGE (OR) 0 – 21 LB (0 – 9.5 KG) RED (RD) 22 – 40 LB (9.6 – 18.2 KG) GREEN (GN) 41 – 85 LB (18.3 – 38.6 KG) BLUE (BL) 86 – 154 LB (38.7 – 70 KG)
M3x2 1923 b black s silver: 23″ X 19″ X 3″ (58.4 X 48.3 X 7.6); 55.7 LB 25.3 KG; RED (RD) 0 – 35 LB (0 – 15.9 KG) GREEN (GN) 36 – 80 LB (16 – 36.4 KG) BLUE (BL) 81 – 149 LB (36.5 – 67.7 KG)
M3x2 1925 b black s silver: 25″ X 19″ X 3″ (63.5 X 48.3 X 7.6); 60.6 LB 27.5 KG; RED (RD) 0 – 31 LB (0 – 14.1 KG) GREEN (GN) 32 – 76 LB (14.2 – 34.5 KG) BLUE (BL) 77 – 145 LB (34.6 – 65.9 KG)
M3x2 2123 b black s silver: 23″ X 21″ X 3″ (58.4 X 53.3 X 7.6); 61.3 LB 27.8 KG; RED (RD) 0 – 30 LB (0 - 13.6 KG) GREEN (GN) 31-75 LB (13.7 – 34.1 KG) BLUE (BL) 76 – 144 LB (34.2 – 65.5 KG)
