Avantgarde Acoustic
TRIO G3
The Trio G3 is Avantgarde Acoustic's German horn-loaded flagship loudspeaker system, built around three redesigned spherical-horn modules — tweeter, midrange, and midbass — mounted on a substantial tripod base with no conventional cabinet (source: [The Audio Beat](https://www.theaudiobeat.com/equipment/avantgarde_trio_g3.htm)). It can be run fully passively with an external amplifier, or converted to an active configuration using Avantgarde's proprietary iTron current-drive amplification, which integrates a three-channel amplifier and active crossover directly into each horn array; the system is typically paired with Avantgarde's SpaceHorn horn-loaded subwoofers for full-range bass extension (source: [The Audio Beat](https://www.theaudiobeat.com/equipment/avantgarde_trio_g3.htm), [Auditorium](https://www.auditorium.de/en/speakers/speakers/floorstanding-speakers/avantgarde-acoustic-trio-g3-active-3-way-horn-system-with-itron)).
MSRP
$91,000
Used market
No tracked sales yet
MSRP to used market
Price history will fill in as sales are recorded.
Specifications
- Weight
- 135 kg (approx. 300 lb) per fully loaded horn array
- Airgate
- Ja
- Gewicht
- 140 kg
- Horntyp
- Sphärisches Horn
- Leistung
- 3 x 100 Watt
- Dimensions
- Width 950mm, Depth 986mm, Height 1,694mm ±15mm (per Auditorium listing for the active iTron configuration)
- Omegadrive
- Ja
- Sensitivity
- >109 dB at 1W/1m
- Driver sizes
- Bass driver 200mm (8"); midrange driver 50mm (2"); treble driver 25mm (1"); Coplanar Driver Alignment horn geometry
- Belastbarkeit
- 150 Watt
- Zero feedback
- Ja
- Frequenzbereich
- 100-28.000 Hz
- Trennfrequenzen
- 100/600/4.000 Hz
- Eintaktschaltung
- Ja
- Abmessungen tiefe
- 986 mm
- Crossover passive
- External passive crossover (Nature Cap, with PolarizationPlus circuit), $4,000/pair option; crossover points at 100 Hz, 600 Hz, and 4,000 Hz; requires external power amplifier
- Hornffnungswinkel
- 180 Grad
- Nominal impedance
- Sources disagree: Auditorium's spec sheet lists 10 ohms; The Audio Beat lists 27 ohms; The Absolute Sound lists 19 ohms — reflecting different measurement conventions or configurations (passive vs. active)
- Nominale impedanz
- 19 Ohm
- Passive ausfhrung
- Ja
- Abmessungen breite
- 950 mm
- Empfohlene raumgre
- > 25 qm
- Frequency response
- 100–20,000 Hz (Auditorium spec); The Audio Beat notes the midbass horns roll off around 140 Hz, requiring subwoofer support above 100 Hz
- Ohne gegenkopplung
- Ja
- Companion subwoofer
- Optional Avantgarde SpaceHorn folded-horn subwoofer (single- or dual-12" driver versions), each with a 1kW internal amplifier and DSP-based bass EQ; priced separately at $65,500/pair (single-driver) or $88,000/pair (dual-driver)
- Cabinet construction
- No conventional cabinet for the horn arrays; horn barrels externally mounted on a vertical extruded housing; heavy tripod base with adjustable spike/glide feet
- Wirkungsgrad 1watt 1m
- > 109 dB
- Abmessungen hhe 15
- 1.694 mm
- Driver horn complement
- Three spherical-horn modules per side: redesigned annular-ribbon tweeter in a spherical tweeter horn; redesigned midrange driver in a spherical midrange horn; redesigned midbass driver in a spherical midbass horn ("trumpet")
- Durchmesser hochtonbereich
- 25 mm / 1 Zoll
- Durchmesser tieftonbereich
- 200 mm / 8 Zoll
- Voll symmetrische schaltung
- Ja
- Durchmesser mitteltonbereich
- 50 mm / 2 Zoll
- Empfohlene verstrkerleistung
- > 2 Watt
- Koplanare treiberausrichtung
- Ja
- Crossover amplification active
- Avantgarde iTron current-drive amplifier: 3-channel, single-ended, feedback-free voltage-to-current converter with integrated active crossover per horn array; supports Tidal, Spotify, DLNA, Roon, and AirPlay streaming
- Horndurchmesser hochtonbereich
- 200 mm
- Horndurchmesser tieftonbereich
- 950 mm
- Horndurchmesser mitteltonbereich
- 570 mm
- Driver sizes per auditorium spec sheet
- Bass driver 200mm (8"); midrange driver 50mm (2"); treble driver 25mm (1"); Coplanar Driver Alignment horn geometry
- High performance multi contact stecker
- Ja
- Itron spannungs strom wandlertechnologie
- patented
- Naturecap inkl polarisationplus schaltung
- Ja
- Voll aktive ausfhrung mit itron verstrker
- Ja
