Pass Labs
XA60.8
Introduced 2014$13,500 MSRP
The Pass Labs XA60.8 is a Class A monoblock power amplifier manufactured by Pass Labs. It delivers 60 W per channel into 8 ohms, with 26 dB gain, a damping factor of 150, and 50 kΩ single-ended or 100 kΩ balanced input impedance. The amplifier has a frequency response of 1.5 Hz–100 kHz, consumes 370 W at idle, and measures 19 × 21.25 × 7.5 inches, weighing 88 lb.
MSRP
$13,500
Used market · Excellent
$9,000
-33% vs MSRP
as of Sep 26, 2026MSRP to used market
From $9,000 at launch to $9,000 today.
Specifications
- Type
- mono power amplifier
- Class
- A
- Inputs
- 1 balanced XLR, 1 RCA
- Gain
- 26 dB
- Outputs
- speaker binding posts
- Topology
- push-pull class A, MOSFET output, single-ended bias
- Weight
- 87 lbs
- Power output
- 60W @ 8 ohms, 120W @ 4 ohms (class A)
- Dimensions
- 19 x 7.6 x 21.2"
- Damping factor
- 150
- Unit weight
- 88 lbs
- Power output ch 8
- 60 Ω
- Full pwr 26 db gain
- 1.10 V
- Low frequency response
- 1.5 Hz
- High frequency response
- 100 KHz
- Unit dimension w x d x h
- 19 x 21.25 x 7.5"
- Input impedance se bal kohms
- 50/100
- Power consumption idle
- 370 W
Active listings (0)
No active listings for this component right now.
Similar but better
Matched by the Audiophilia engine on character, specs and market position.
Peers
Pass Labs · headphone-amplifiers
X600.8
Price on request
- A close peer to this component
Pass Labs · headphone-amplifiers
XA160.8
Price on request
- A close peer to this component
Pass Labs · headphone-amplifiers
XA30.8
