Quad

Revela 1

The Quad Revela 1 is a two-way bookshelf/standmount loudspeaker with a bass-reflex enclosure, a 165 mm advanced-fibre-cone bass/midrange driver, and a 27 × 60 mm True Ribbon treble driver. Its phase-compensated Acoustic Butterworth crossover operates at 2.9 kHz, with a 6 Ω nominal impedance, 86 dB sensitivity, 54 Hz–24 kHz ±3 dB frequency response, and 40 Hz bass extension at −6 dB. The cabinet has a 17.6-litre volume and is available in Piano Walnut/Piano Black or Piano Black finishes, with an optional custom-engineered stand.
