Analog Audio Design
TP-1000
Introduced 2022$27,000 MSRP
The TP-1000 is a playback-only, two-track quarter-inch reel-to-reel deck designed and hand-built in Brittany, France, by Christophe Martinez, combining a touchscreen-controlled transport with strain-gauge tape-tension sensing and Studer-spec (AM Belgium) playback heads (The Absolute Sound).
MSRP
$27,000
Used market
No tracked sales yet
We only show a used value once a real sale or listing price has been recorded for this component.
MSRP to used market
Price history will fill in as sales are recorded.
Specifications
- Motors
- 3 (servo-controlled)
- Weight
- 61.73 lbs (28kg)
- Dimensions
- 466mm × 519mm × 305mm
- Speeds
- 3.75/7.5/15 ips
- Tape format
- 1/4 in (6.35mm), 2-track/2-channel, DIN track spacing
- Tape speeds
- Switchable 15 ips (38.1 cm/s) and 7.5 ips (19.05 cm/s), accuracy within ±0.05%
- Connectivity
- XLR balanced/unbalanced I/O, headphone out, RJ45 Ethernet for remote control and firmware updates
- Heads motors
- Tape heads from AM Belgium (same as Studer A800/A810/A812/A820); Maxon (Switzerland) DC reel motors
- Track format
- 2-track (half-track) stereo
- Wow and flutter
- <0.045% peak weighted at 15ips (DIN 45507)
- Max reel size
- 10.5"
- Frequency response
- 30Hz–22kHz (±2dB) at 15ips; 30Hz–20kHz (±2dB) at 7.5ips
- Signal to noise ratio
- 71dB/78dB (CAL/A-weighted) at 15ips
