Nagra

LB

MSRP not recorded

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

Tracks: 2 individual
Display: 2 x Colour LCD
Ethernet: RJ 45
Limiters: On microphone inputs
USB host: USB 2.0 connector type “A”
Bit rates: 32 kbits/s up to 384 kbits/sec
File type: 16 / 24 bit Broadcast Wave File BWF (WAV)
Headphones: Stereo 6.3mm (¼”) Jack 50 Ω
USB device: USB 2.0 connector type “B”
Weight: 1.4 kg (3 lbs) (Incl. batteries)
Charge time: Approximately 3 hours (with NimH cells)
Disk format: FAT 16 / 32
M s decoder: Switchable
Battery life: 8 hours (8 x NiMh 2500 mAh) Record @ 24 bits 48 kHz with 2 x phantom +48V (2 x 4 mA), continuous recording. Between 5 and 5 1/2 hours with 8 x LR6 dry alkaline cells.
Level meters: On colour display AND by LED
Power supply: External 9 – 15V
THD at 1: <0.1% Mic, <0.01% line (measured on AES out) kHz
Digital input: XLR 3-pole
Dimensions: 175 x 65 x 185mm (W x H x D) (Incl. battery box)"
Input filters: LFA (with vortex filtering)
Sampling rate: 44.1, 48 kHz, 88.2, 96 and 192kHz
Digital output: XLR AES-3 (24 bit or 16 bit)
Analogue inputs: 2 x XLR Microphone (Dynamic, +48V Phantom) / line
Removable media: Compact Flash type II / III (Hot Swappable)
Internal speaker: 0.2W
Internal storage: 2 GB NAND Flash memory
Recording method: Linear digital PCM, MPEG 1 layer 2 or MP-3
Power consumption: Approximately 2W (160mA on 12V)
Relative humidity: From 10% to 99% (non condensing)
Frequency response: Mic, 10Hz – 48 kHz ± 0.5 dB, Line ±0.2 dB (measured on AES out)
Recording capacity: 1hr 24 bit 48 kHz per GB of disk / memory
A d d a conversion: 24 Bit Sigma Delta
Internal microphone: Electret on the front panel
Analogue line output: XLR 4.4V max (+15 dBm)
Pre recording buffer: Programmable (Maximum 3 seconds)
Signal to noise ratio: >100 dB
Line input sensitivity: Adjustable from -6 dBm up to +24 dBm for 0 dBFS recording
Input level adjustment range: 50 dB Mic and from -6 to +24 dB Line
Microphone input sensitivity: 2 and 15 mV/Pa selectable
2 channels 24 bit 192 khz ad da: MPEG-1 layer II MP-3 compression
USB 20 and ethernet communication ports: Internal speaker Pre-recording buffer
Compact flash and internal 2gb flash memory: On-board graphic audio editor
Dual colour screens and bluetooth communication: Lightweight and battery operated
