Furutech

FP-314Ag II

The Furutech FP-314Ag II is a 50 m/reel power supply cable with a listed 15 AWG α-conductor specification (1.82 sq. mm). Its topology comprises two 0.25 mm-diameter cores and one 0.25 mm-diameter core, each using 37-strand α Alpha μ-OFC conductors, with red, white, and green polyethylene insulation assigned to L, N, and E. The cable includes a 9 × 24-strand, 0.12 mm braided α Alpha conductor shield, a black RoHS-compliant vibration-suppression PVC inner sheath measuring 9.3 mm in diameter, and a brown RoHS-compliant flexible PVC outer sheath measuring approximately 12.9 mm in diameter.
