Nagra

REFERENCE DAC

MSRP not recorded

The Nagra Reference DAC is a digital-to-analog converter manufactured by Nagra Audio, with 1× AES/EBU, 2× S/PDIF, 2× Nagra-Link, 1× optical, and 1× USB audio input, plus stereo RCA and stereo XLR outputs. It uses dual chassis power supplies—one for the audio signal section and one for the digital section, controls, and relay switching—with custom-made capacitors, high-voltage supplies generating a 200 V DC grid tension, and added super-capacity; its top cover contains a phenolic damping layer. The DAC has a 1.5 VRMS output level, output impedance below 200 ohms, frequency response of 5 Hz–40 kHz (+0/−1 dB), and separate 433×436×121 mm power-supply and audio-device chassis weighing 16.5 kg and 13.5 kg respectively.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

Crosstalk: > 110 dB @ 1 kHz > 100 dB @ 20 kHz
Distortion: < 0.02 % @ -20 dBfs < 0.005 % (H2 filtered) @ -3 dBfs
Mains fuse: S230V~ to 240V~ -> T 2A L (FST 5x20mm 250V) 100V~ to 127V~ -> T 3.15A L (FST 5x20mm 250V)
Weight: Power supply chassis (HD PSU) 16.5 kg (36.38 lb) Audio device chassis 13.5 kg (29.77 lb) lbs
Mains power: 100V~, 115V~, 120V~, 127V~, 230V~ or 240V~ NOT ADJUSTABLE ±10%, 50-60Hz
Output level: 1.5 VRMS
Dimensions: Power supply chassis (HD PSU) 433x436x121 mm (17.05 17.17 4.76 in) Audio device chassis 433x436x121 mm (17.05 17.17 4.76 in)"
Analog outputs: 1 stereo RCA 1 stereo XLR
Digital inputs: 1x AES/EBU, 2x S/PDIF, 2x NAGRA-LINK, 1x Optical, 1x Audio USB (UCA2)
Home automation: 1x SUB-D9 connector RS232 115200 bits/s, 8 data bits, no parity, 1 stop bit
Output impedance: < 200 ohms
Power consumption: 170W max
Remote automation: Input 1x 3.5mm (1/8”) stereo jack socket Input command Output 4x 3.5mm (1/8”) stereo jack socket Output switching by relay
Frequency response: 5 Hz 40 kHz +0 / -1 dB
Inter channel phase: < 0.05 ° @ 1 kHz < 0.3 ° @ 20 kHz < 0.5 ° @ 50 kHz
Operating environment: Indoor only IP30
Operating temperature: +15°C to +35°C (+59°F to +95°F) moderate climate
Analog output noise level: -128 dBr @ 1 kHz 1.5 V Unweighted
