Nagra

VII Anniversary

MSRP not recorded

The Nagra VII Anniversary Edition is a portable digital audio recorder made by Nagra to mark the 70th anniversary of the first Nagra, introduced in 1951. Electronically identical to the Nagra SEVEN, it has a front panel, aluminum controls, red and green potentiometers, and battery compartment machined from solid aluminum. It provides two analog microphone/line inputs, a stereo AES-42 digital input, 24-bit Sigma Delta A/D and D/A conversion, PCM recording up to 192 kHz, optional MPEG-1 Layer II recording, two tracks, removable SD storage, and AES-3 digital output.

MSRP

—

Original list price not on record.

Used market

No tracked sales yet

We only show a used value once a real sale or listing price has been recorded for this component.

Sell or trade this Add to my system

MSRP to used market

Price history will fill in as sales are recorded.

Specifications

USB: Micro AB connector
1khz: 2.8mV Mic <0.2%，10mV Mic <0.1%，线路 <0.1%（在 AES 输出上测量）
Tracks: 2 individual
Display: Color LCD touchscreen
A d d a: 24 Bit Sigma Delta
Ethernet: RJ 45
Limiters: On microphone inputs
Bit rates: 32 kbits/s up to 384 kbits/sec
Crosstalk: Mic >70dB : Line > 110dB
File type: 16 / 24 bit Broadcast Wave File BWF (WAV)
Headphones: Stereo 6.3mm (¼”) Jack 50 Ω
Weight: 800g (1.75 lbs) (Incl. battery pack)
Charge time: Approximately 3 hours
Disk format: FAT 16 / 32
M s decoder: Switchable
THD: <0.004%%
Battery life: >5 hours
Level meters: On colour display
Power supply: External 15V
THD at 1: 2.8mV Mic <0.2%, 10mV Mic <0.1%, line <0.1% (measured on AES out) kHz
Digital input: XLR 3-pole / AES 42
Dimensions: 165 x 175 x 65mm (W x D x H) (Incl. battery box)"
Input filters: LFA
Sampling rate: 44.1, 48, 88.2, 96, 176.4 and 192kHz
Digital output: XLR AES-3 (24 bit or 16 bit)
Analogue inputs: 2 x XLR Microphone (Dynamic, +48V Phantom) / line
Mic input noise: Uin < 1µV (2.8 and 10 mV) @ 220Ω Uin < 1.6µV (40 mV)
Removable media: SD Flash memorycard
Internal speaker: 0.3W
Internal storage: Micro SD Flash memory card
Recording method: Linear digital PCM, optional:MPEG 1 layer II
Power consumption: Approximately 5W
Relative humidity: From 10% to 99% (non condensing)
Frequency response: Mic, 10Hz – 75 kHz (+0 – 3dB), Line 10 Hz – 90 kHz (+0 -1dB) (measured on AES out)
Recording capacity: 1hr at 24 bit 48 kHz per GB of memory
Internal microphone: On the front panel
Analogue line output: XLR 4.4V max (+15 dBm)
Pre recording buffer: Programmable
Input level adj range: 42 dB Mic and from -6 to +24 dB Line
Mic input sensitivity: 2.8, 10 and 40 mV/Pa selectable
Signal to noise ratio: >110 dB ASA “A”
Line input sensitivity: Adjustable from -6 dBm up to +24 dBm for 0 dBFS recording
